How to Install a Short Shifter in a 2014 Subaru BRZ

If you own a 2014 Subaru BRZ and have ever wanted a quicker, more engaging gear change, a short shifter upgrade is the simplest way to feel the difference. By reducing the throw distance, you shave seconds off each shift and add a sportier feel without compromising reliability. This guide walks you through choosing the right kit, gathering tools, and completing the install step by step.

2014 Subaru BRZ Short Shifter Upgrade: What to Expect

A factory shifter on the BRZ moves roughly 30‑35 mm between gears. Most aftermarket short‑shifter kits cut that travel by 10‑15 mm, translating to a noticeably snappier feel. You’ll also notice a firmer pivot point and a slightly higher shift lever position. The change is purely mechanical—no ECU re‑flash is required—so the upgrade is reversible if you ever decide to sell the car.

Choosing the Right Kit

Not all short shifters are created equal. Here are the three most common options for the 2014 model year:

• OEM‑style kits retain the original lever shape but shorten the pivot. Ideal for drivers who want a subtle improvement without altering the interior aesthetics.
• Racing‑grade kits feature a bespoke lever, often with a matte‑black finish and a more aggressive angle. These give the biggest reduction in throw but may require minor clearance adjustments.
• Adjustable kits let you fine‑tune the throw length via a set of interchangeable bushings. They’re perfect for enthusiasts who like to experiment.

When comparing kits, check the manufacturer’s specifications for throw reduction, required hardware (e.g., new bushings, bolts), and whether any interior trim removal is necessary. Reviews on forums such as SubaruOutback.org often highlight real‑world fitment quirks, so a quick browse can save you a surprise.

Tools and Preparation

Gather the following before you lift the car:

• Socket set (metric 10 mm, 12 mm, 14 mm)
• Torx bits (T20, T25)
• Trim removal tools (plastic pry bars)
• Penetrating oil
• Torque wrench (calibrated to 8‑10 Nm for shifter bolts)
• Clean rags and a mild degreaser

Park on a flat surface, engage the parking brake, and disconnect the battery. Though the shifter isn’t directly tied to any electrical components, it’s good practice to avoid accidental short circuits when you remove interior panels.

Step‑by‑Step Installation

1. Remove the Center Console

Start by taking off the gear‑shift knob—usually secured with a set screw hidden beneath a small plastic cap. Use a flat‑head screwdriver to pop the cap, then loosen the screw with a Torx T20. Pull the knob straight up.

Next, release the trim clips surrounding the console. A gentle pry with a plastic tool will free the lower panel without cracking the surrounding plastic. Once the panel is down, you’ll see the shifter housing and its mounting bolts.

2. Detach the Factory Shifter

Apply a light coat of penetrating oil to the two bolts that clamp the shifter to the transmission. After a few minutes, remove them with a 12 mm socket. Carefully pull the shifter assembly upward; it should come free with minimal resistance.

Inspect the bushings for wear. If they’re cracked or excessively soft, replace them with the new ones supplied in your short‑shifter kit.

3. Install the Short‑Shifter Components

Position the new shifter lever in the housing, aligning the bolt holes with the factory‑drilled tabs. Insert the supplied bushing—most kits use a polymer or aluminum insert that reduces play. Tighten the mounting bolts to the manufacturer‑specified torque (usually 8 Nm).

If you opted for an adjustable kit, swap the default bushing for a shorter one to achieve the desired throw. Some drivers like to start with the longest bushing and work downwards until the shift feel feels right.

4. Reassemble the Console

Slide the shifter back into the console, ensuring the linkage moves freely. Replace the trim panel, snapping the clips back into place. Re‑install the gear‑shift knob, torque the set screw to about 2 Nm, and snap the cap back on.

Reconnect the battery, start the engine, and cycle through each gear. You should notice a tighter, quicker shift with the reduced travel distance.

Tuning and Final Checks

After the mechanical work, it’s wise to double‑check a few details:

• Make sure the shifter returns to neutral without binding.
• Listen for any abnormal noises when shifting under load; excessive clunking may indicate an incorrectly seated bushing.
• Verify that the gear‑shift knob is firmly attached—loose knobs can become safety hazards.

If anything feels off, loosen the mounting bolts by a quarter turn and re‑align the lever. Small adjustments often make a big difference in perceived shift quality.

Common Pitfalls to Avoid

Clearing interference. Some racing‑grade kits sit higher, which can rub against the console lip. If you notice contact, gently sand the offending area or choose a lower‑profile lever.

Over‑torquing bolts. The shifter housing is cast aluminum; excessive torque can crack the threads. Stick to the recommended torque range.

Neglecting bushing lubrication. Even polymer bushings benefit from a thin layer of high‑temperature grease to prevent squeal during aggressive shifts.

FAQ

Will a short shifter affect my warranty?

Generally, no. The upgrade only replaces interior hardware and does not alter engine or transmission components. However, keep the original parts and receipts in case you need to revert the modification for a warranty claim.

Do I need to modify the shift linkage?

Most kits are designed as direct replacements, so the existing linkage works fine. Only a few ultra‑short kits require a minor length adjustment, which the manufacturer will note in the instructions.

Can I install the short shifter myself, or should I go to a shop?

The job is straightforward for anyone comfortable with basic hand tools and interior trim removal. It typically takes 1‑2 hours. If you’re unsure about handling the delicate trim clips, a quick visit to a Subaru specialist can save time.

Will the shorter throw affect my daily driving comfort?

Most drivers find the change pleasant, but if you frequently drive in heavy traffic, the firmer feel can be a bit more demanding. Many choose an adjustable kit to dial in a balance between sportiness and ease of use.
